Automated flows guide designers through the analysis process step by step and produce detailed reports and waveforms that document the design’s operating voltage and timing margins.

HyperLynx Signal Integrity HyperLynx SI makes signal integrity analysis accessible to everyone by combining industry-leading ease of use with a focus on standards-based design and compliance analysis.

Integrated 3D EM solvers create highly accurate interconnect models. The HyperLynx family provides a complete analysis flow that combines best-practice design rule checking with comprehensive signal and power integrity simulation. HyperLynx works with multiple PCB tools and is an ideal addition to any PCB design flow. This allows problems to be identified and resolved early in the design cycle.

HyperLynx combines ease of use with automated workflows to make high-speed design analysis accessible to mainstream system designers. Simple copying the file extracta.exe into the working directory doesn't resolve the problem - the error messages are the same.Scalable High-speed System Design & Verification brd file in HyperLynx, extraction fails and I see the following message in log file:ĮRROR: Could not run Cadance Allegro utility: extracta.ĮRROR: Could not convert file 'D:\PROJ\layouts\aaa.brd' to file '"D:\PROJ\layouts\aaa.a_b"' And I've found extracta.exe in the following directory: C:\Cadence\SPB_16.5\tools\pcb\bin. When I try to extract. What does it mean "fully installed" ? I've Cadence Allegro SPB 16.5 installed. Note that Allegro FREE Physical Viewer does not include Extracta. Cadence Allegro and Allegro Physical Viewer (also known as Cadence Viewer Plus) include Extracta. It is not sufficient to copy the Extracta executable file to the computer. The Cadence Extracta ASCII-extraction utility must be fully installed on the computer to create the ASCII version of the design.
